Ruijie
RG-S6990-128QC2XS 128-Port 400GE Fixed Switch for AIGC Intelligent Computing Networks
Model: RG-S6990-128QC2XS
Pricing for this product is provided on request.
Request a quote128-Port 400GE Fixed Switch for AIGC Intelligent Computing Networks. The RG-S6990-128QC2XS is a next-generation, high-performance, and high-density fixed switch launched by Ruijie Networks for high-end data centers and AIGC intelligent computing networks. The high-speed and high-density core switch provides 128 x 400GE ports housed in a 4-RU enclosure, delivering scalable, high-performance, and high-bandwidth services for large-scale DCI networks.
Specifications
| Service port | 128 x 100G/200G/400G QSFP112 ports; 2 x GE/10GE SFP+ ports |
| Management port | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| Switching capacity | 102.4 Tbps |
| Packet forwarding rate | 21000 Mpps |
| Power consumption | Maximum power consumption: 3160 W; Typical power consumption: 2432 W; Static power consumption: 433 W |
| Dimensions; (W x D x H) | 446 mm x 800 mm x 173.6 mm (17.56 in. x 31.5 in. x 6.84 in.) |
| Unit weight | 37.6 kg (82.89 lbs., empty chassis); 45 kg (99.21 lbs., a chassis with four power modules and five fan modules) |
| Rack height | 4 RU |
| Operating temperature | 0°C to 40°C (32°F to 104°F) |
| Operating humidity | 10% RH to 90% RH (non-condensing) |
| Model | RG-S6990-128QC2XS |
Need installation or a bulk quote? Talk to our team.
