Ruijie
RG-S6160-48VS8CQ-X Series Next-Generation 48-Port 10GE All-Optical Layer 3 Core/Aggregation Switch with 100 Gbps Uplinks
Model: RG-S6160-48VS8CQ-X
Pricing for this product is provided on request.
Request a quoteNext-Generation 48-Port 10GE All-Optical Layer 3 Core/Aggregation Switch with 100 Gbps Uplinks. Highlights: VSU for Flexible Networking and High Performance; Multiple Hardware-Level Protections for Continuous Operation; Layer 3 Routing Capabilities for Diverse Services and Efficient and Reliable Transmission.
Specifications
| Fixed service port | 48 x 1G/2.5G/10G/25G (25G supported by the license) SFP28 ports; 8 x 40G/100G QSFP28 ports (Each 40G port can be split into four 10G ports or each 100G port can be split into four 25G ports.) |
| Fixed management port | 1 x MGMT port; 1 x console port |
| Switching capacity | 4 Tbps |
| Packet forwarding rate | 915 Mpps |
| PoE | Not supported |
| Power module | RG-PA550I II-F |
| Maximum Power Consumption | 300 W |
| Unit dimensions (W x D x H) | 442 mm x 387 mm x 44 mm (17.40 in. x 15.24 in. x 1.73 in.) |
| Operating temperature | 0°C to 45°C (32°F to 113°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Model | RG-S6160-48VS8CQ-X |
Need installation or a bulk quote? Talk to our team.
