RG-S6120-20XS4VS2QXS 20-Port 10GE Layer 3 Managed Core and Aggregation Switch
Model: RG-S6120-20XS4VS2QXS
Pricing for this product is provided on request.
Request a quote20-Port 10GE Layer 3 Managed Core and Aggregation Switch. A Red Dot Design Award winner. Recommended core or aggregation switch for small and medium-sized enterprise deployment.
Specifications
| Fixed service port | 20 x 1GE/2.5GE/10GE SFP+ ports; 4 x 10GE/25GE SFP28 ports; 2 x 40GE QSFP+ ports |
| Fixed management port | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| System switching capacity | 912 Gbps |
| System packet forwarding rate | 678 Mpps |
| Module slot | 2 x power module slots; 2 x fan module slots |
| Unit dimensions (W x D x H) | 440 mm x 330 mm x 43.6 mm (17.3 in. x 12.99 in. x 1.72 in.) |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Warranty duration | 3 years |
| Power module | RG-PA150IB-F |
| Maximum power consumption | 85 W |
| Unit weight | 4.6 kg (10.14 lbs, with two fan modules) |
| Rack height | 1 RU |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 200,000 hours (about 22 years) |
| Model | RG-S6120-20XS4VS2QXS |
