Ruijie
RG-S6110-24MG4VS-UP 24-Port 5GE Managed Multi-GE Access Switches with 25GE Uplink Ports
Model: RG-S6110-24MG4VS-UP
Pricing for this product is provided on request.
Request a quote24-Port 5GE Managed Multi-GE Access Switches with 25GE Uplink Ports. 5G/2.5G/1G/100M access, PoE/PoE+/PoE++, 4 x 25G uplink optical ports, offering flexible networking options to build high-performance campus networks. 24 x 100/1000/2.5G/5GBASE-T ports and 4 x 10GE/25GE SFP28 uplink ports are provided to realize flexible networking.
Specifications
| Fixed service port | 24 x 100/1000/2.5G/5GBASE-T ports, supporting PoE/PoE+/PoE++; 4 x 10GE/25GE SFP28 ports |
| Fixed management port | 1 x RJ45 console port; 1 x RJ45 MGMT port |
| System switching capacity | 528 Gbps |
| System packet forwarding rate | 392 Mpps |
| PoE port | Ports 1 to 24 support PoE/PoE+/PoE++ (IEEE802.3af/at/bt) power supply |
| Power module | Not Supported |
| Maximum power consumption | 90 W (without PoE); 460 W (full PoE load) |
| Unit dimensions (W x D x H) | 442.0 mm x 220.0 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.) |
| Unit weight | 3.71 kg (8.18 lbs) |
| Rack height | 1 RU |
| Operating temperature | 0°C to 45°C (32°F to 113°F) |
| Operating humidity | 10% to 90% RH (non-condensing) |
| Mean time between failure (MTBF) | 194,296 hours (about 22 years) |
| Model | RG-S6110-24MG4VS-UP |
Need installation or a bulk quote? Talk to our team.
