RG-MAP920-SF-M(V3) Simplified Optical Ethernet (SOE) Micro AP
Ruijie
RG-MAP920-SF-M(V3) Simplified Optical Ethernet (SOE) Micro AP
Model: RG-MAP920-SF-M(V3)
Pricing for this product is provided on request.
Request a quoteThe RG-MAP920-SF-M(V3) is a simplified optical Ethernet (SOE) micro AP. Suitable for dormitories, private offices, hotel rooms, and similar scenarios. Key features: 2.5GE SFP port for ultra-Gigabit high-speed indoor access; Enterprise-class Wi-Fi 7 delivering a data rate of up to 3.570 Gbps.
Specifications
| Wi-Fi standard | 802.11n/ac/ax/be |
| Ports | 1 x 2.5G SFP port, which is compatible with the 1G SFP transceiver; 4 x 10/100/1000BASE-T ports; 1 x micro USB console port; 1 x Bluetooth 5.3 |
| Dimensions (W x H x D) | 86 mm x 160 mm x 38 mm (3.39 in. x 6.30 in. x 1.5 in.) |
| Weight | Main unit: 0.45 kg (0.99 lbs); mounting bracket: 0.05 kg (0.11 lbs) |
| Max power consumption | 12 W |
| Power supply | 48 V DC/0.25 A over the DC connector; IEEE 802.3af PoE input using hybrid cables |
| Operating temperature | -10°C to +40°C (14°F to 104°F) |
| Mounting | Mounting in the 86 mm x 86 mm (3.39 in. x 3.39 in.) junction box or wall-mounting |
| Max associated clients | 1,024 (up to 256 STAs per radio) |
| Model | RG-MAP920-SF-M(V3) |
Need installation or a bulk quote? Talk to our team.
