RG-ANT30-D2 Dual-Band Directional High-Gain Outdoor Antenna
Model: RG-ANT30-D2
Pricing for this product is provided on request.
Request a quoteThe RG-ANT30-D2 is a dual-band directional high-gain outdoor antenna. Suited to offices, hotels, warehouses, hospitals, and schools. Key features: High-performance dual-band directional outdoor antenna for directional coverage in either the 2.4 GHz or 5 GHz band; 14 dBi peak gain on 5 GHz and 12 dBi on 2.4 GHz for stronger, longer-range signals.
Specifications
| Operating frequency bands | Band 1: 2400–2500 MHz; Band 2: 5150–5850 MHz |
| Polarization | Vertical and horizontal polarization |
| Antenna gain | Band 1: 12 dBi; Band 2: 15 dBi |
| 3-dB azimuth beamwidth | Band 1: 40°±5°; Band 2: 20°±3° |
| 3-dB elevation beamwidth | Band 1: 40°±5°; Band 2: 20°±3° |
| Antenna connector | 2 x RP-SMA female antenna connectors |
| Housing material | PC |
| Dimensions (W x D x H) | 220.5 mm x 167 mm x 167 mm (8.68 in. x 6.57 in. x 6.57 in.) |
| Unit weight | 0.65 kg (1.43 lbs, without the mounting bracket) |
| Color | White |
| Maximum input power | 43 dBm per port |
| IP rating | IP55 |
| Mounting | Wall-mount and pole-mount |
| Certification | CE |
| Model | RG-ANT30-D2 |
