RG-AM5832-SF-P Simplified Optical Ethernet (SOE) Master Access Point
Ruijie
RG-AM5832-SF-P Simplified Optical Ethernet (SOE) Master Access Point
Model: RG-AM5832-SF-P
Pricing for this product is provided on request.
Request a quoteThe RG-AM5832-SF-P is a simplified optical Ethernet (SOE) master access point. Recommended for deployment in schools, hotels, medical care, office, production workshops, etc. Key features: Hybrid cables, simplifying optical network deployment; Rich port options to adapt to various APs and achieve flexible service expansion.
Specifications
| Ports | Uplink: optional subcards, 2 x 40GE QSFP+ ports (RG-M5800-2QXS) or 8 x 25GE SFP28 ports (RG-M5800-8VS); downlink: 24 x 10GE SFP+ ports (compatible with 2.5GE and 1GE modules) and 24 PoE-out ports (PoE/PoE+/PoE++, up to 90 W per port, 1,600 W maximum) |
| Management ports | 1 x RJ45 10/100/1000Base-T auto-negotiation management port; 1 x RJ45 console port |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.) |
| Weight | 5.85 kg (12.90 lbs) |
| Rack height | 1 RU |
| Max power consumption | < 200 W (without load); < 2,000 W (full load) |
| Power supply | Supports two hot-swappable 1,000 W AC power modules (one AC power module is delivered, a second can be purchased) |
| Operating temperature | 0°C to 45°C (32°F to 113°F) at an altitude in the range of 0 m to 1,800 m (5,905.51 ft.) |
| Mounting | Rack-mount |
| Max associated clients | 1,536 |
| Model | RG-AM5832-SF-P |
Need installation or a bulk quote? Talk to our team.
